THINKCAR THINKTOOL PRO Car Diagnostic Scanner OBDII Tool
THINKTOOL Pro is a new generation modular intelligent diagnostic equipment based on Android 10system developed by THINKCAR. THINKTOOL Pro can be widely applied in various scenarios with our unique modular design.
THINKCAR THINKTOOL PRO Main Function:
☛1. The main unit and diagnostic connector support Bluetooth and wired communication. Wired communication is superior to Bluetooth connection in terms of transmission rate and anti-interference. Also, a wired connection is recommended for online programming functions.
☛2. Supports powerful intelligent VIN recognition technology, which is convenient, fast and efficient.
☛3. Quick Check Printing: Automatic identification of Vehicle Information, Auto Check and Report Printing
☛4. Modular expansion: Support 8 optional modules: printer, work light, video scope, battery tester, scope box, thermal imager, moudledock, wireless TPMS tool（note: you can buy those models on ThinkStore）
☛5. It can detect faults in the electronic control systems of most high-, medium-, and low-end vehicles in Asia, Europe, the United States and China. Powerful diagnostic functions include reading fault codes, clearing fault codes, reading data streams, action tests, and special functions.
☛6. Maintenance function:matching, coding, programming of most vehicles’ programable modules, and most commonly used maintenance and reset functions: Oil Reset, Elec. Throttle Adaption, IMMO Service, Injector Coding, Break-pad Reset, Steering Angle Reset, ABS Bleeding, AFS Reset, Battery Matching, A/T Learning, DPF Regeneration, EGR Adaption, TPMS Reset, Sunroof Initialization, Suspension Matching, Gear Learning, Airbag Reset, ODO Meter Reset, AdBlue Reset, A/F Reset, Coolant Bleeding, Language Change, NOx Sensor Reset, Seat Calibration, Stop/Start Reset, Transport Mode, Tyre Reset, Windows Calibration.
☛7. Online one click to update diagnosis software, client and firmware.
☛8. Feedback: Any abnormal software or function during the diagnosis, just feedback to us, our professional technician will track and deal with it in time.
with wireless TPMS tool (optional), TPMS activation, programming and learning functions can be supported. （note: you can buy those SEPARATELY）
To diagnose cars comprehensively, Thinktool Pro scanner can read DTCs and data streams, perform active test, Coding for ALL systems.
Engines/Auto Transmission/Airbags/Immobilizer/Key Coding/ABS/Cruise Control/Instruments/ Self Leveling Suspension systems/Seats/Doors/Gateway/Steering Angle/Air Suspension/Body Systems/Electronic Power Steering & Motor Assisted/Power Steering/Tyre Pressure/Rain Sensors/4WD System/Stabilizer/Intelligent Parking Assist/Door Motors/Audio Systems/Air Conditioning/Tiptronic/Anti Theft/Soft Top/Headlamp Leveling/Central Locking/Automatic Clutch/ DPF Reset/Electric Windows/Plip Programming/Heated Rear Window/Xenon Headlights/Wash Wipe/Fuel Burning Heater/Transfer Box/Seat Memory/Oil Life Service Reset/Sliding Doors/Electronic Throttle/Navigation System/Rollover Sensor/Cruise Control/ Multi Functios.
This function is used to test whether the execution components in the electronic control system can work
The Coding function is used to re-flash the vehicle control modules, it allows you to reprogram adaptive data for certain components after making repairs or replacements.
Combine: Displayed in graph merge status for data comparison.
Displayed the parameters in values and shown in list format.
Customize the data stream option to be viewed. Tap the button, a pull-down list of the data stream items appears on the screen. Select the desired items (max12 items), and then the screen will display the waveforms corresponding to these items immediately. If need to remove any items, just deselect them.
If you encounter an unresolved problem or diagnostic software bug during diagnosis, you can revert the most recent 20 test records to Thinkcar Team. When we receive your feedback, we will analyze and troubleshoot it in a timely manner, to improve the quality of our products and user experience.
Quick print diagnostic reports：
Thermal printer, work with the main unit, also can work with module dock. Quick print diagnostic reports anytime and anywhere.
English, France, Germany, Spanish， Italy, Portugal, Japan, Russia, Chinese
Technical Support Service
THINKTOOL Pro Support 28+ Kinds of Special Reset
1、Oil Reset The lightening of the car maintenance light indicates that the vehicle needs maintenance.Reset the mileage or driving time to zero after the maintenance, so the maintenance light will go out and the system will start a new maintenance cycle.
2、Elec.Throttle Adaption Elec. Throttle Adaption is to utilize the car decoder to initialize the throttle actuator so that the learning value of the ECU returns to the initial state.
3、Steering Angle Reset To reset the steering angle, first find the relative zero point position for the car to drive in a straight line. Taking this position as a reference, the ECU can calculate the accurate angle for left and right steering.
4、Battery Matching This function enables you to perform a resetting operation on the monitoring unit of the vehicle battery, in which the original low battery fault information will be cleared and battery matching will be done.
5、ABS Bleeding When the ABS contains air, the ABS bleeding function must be performed to bleed the brake system to restore ABS brake sensitivity.
6、Break-pad Reset lf the brake pad wears the brake pad sense line, the brake pad sense line sends a signal sense line to the on-board computer to replace the brake pad. After replacing the brake pad, you must reset the brake pad. Otherwise, the car alarms.
7、DPF Regeneration DPF regeneration is used to clear PM (Particulate Matter) from the DPF filter through continuous combustion oxidation mode (such as high-temperature heating combustion, fuel additive or catalyst reduce PM ignition combustion) to stabilize the filter performance.
8、Gear Learning After the engine ECU, crankshaft position sensor, or crankshaft flywheel is replaced, or the DTC ‘gear not learned’ is present, gear learning must be performed.
9、IMMO Service To prevent the car from being used by unauthorized keys, the anti-theft key matching function must be performed so that the immobilizer control system on the car identifies and authorizes remote control keys to be normally used the car.
10、Injector Coding Write injector actual code or rewrite code in the ECU to the injector code of the corresponding cylinder so as to more accurately control or correct cylinder injection quantity.
11、TPMS Reset Note: Cooperate with wireless tire pressure diagnosis tool to realize TPMS activation, programming and learning function
12、Suspension Matching This function can adjust the height of the body. When replacing the body height sensor in the air suspension system, or control module or when the vehicle level is incorrect, you need to perform this function to adjust the body height sensor for level calibration.
13、AFS Reset This feature is used to initialize the adaptive headlamp system.
14、A/T Learning This function can complete the gearbox self-learning to improve gear shifting quality.
15、Sunroof Initialization This function can set the sunroof lock off, closed when it rains, slide/tilting sunroof memory function, temperature threshold outside the car etc.
16、EGR Adaption This function is used to learn the EGR valve after it is cleaned or replaced.
17、ODO Reset ODO reset is to copy, write, or rewrite the value of kilometres in the chip of odometer by using a car diagnostic computer and data cable, so that the odometer shows the actual
18、Airbag Reset This function resets the airbag data to clear the airbag collision fault indicator.
19、Transport Mode ln order to reduce power consumption, the following functions may be disabled, including limiting the vehicle speed, not waking up the door opening network, and disabling the remote control key, etc.At this time, the transport mode needs to be deactivated to restore the vehicle to normal.
20、A/F Reset This function is applied to set or learn Air/Fuel ratio parameters.
21、Stop/Start Reset This function is used to open or close the automatic start-stop function via setting the hidden function in ECU(provided that the vehicle has a hidden function and is supported by hardware).
22、NOx Sensor Reset NOx sensor is a sensor used to detect the content of nitrogen oxides (NOx) in engine exhaust. lf the NOx fault is re-initialized and the NOx catalytic converter is replaced, it is necessary to reset the catalytic converter learned value stored in the engine Ecu.
23、AdBlue Reset (Diesel Engine Exhaust Gas Filter) After the diesel exhaust treatment fluid (car urea) is replaced or filled up, the urea reset operation is required.
24、Seat Calibration This function is applied to match the seats with memory functions that are replaced and repaired. 25、Coolant Bleeding Use this function to activate the electronic water pump before venting the cooling system.
26、Tyre Reset This function is used to set the size parameters of the modified or replaced the tire.
27、Windows Calibration This feature is designed to perform door window matching to recover ECU initial memory and recover the power window’s automatic ascending and descending function.
28、Language Change This function is used to change the system language of the vehicle central control panel. …….
Diagnostic function, coverage of more than 100 car brands, support intelligent diagnosis and traditional diagnosis, including OBD II full-function diagnosis, full-system diagnosis including reading fault code, clear fault code, read real-time data stream, special function, auction test. A diagnosis report can be generated after the diagnosis.
