AUTEL NEW 2023 IM608S II Full Kit Diagnostic Key Programming Scanner Tool

AUTEL IM608S II Full kit Diagnostic Key Programming and ECU Coding Tool

3,995.00 including 23% VAT Rate


Add-ons total:


AUTEL NEW 2023 IM608S II Full Kit Diagnostic Key Programming Scanner Tool

PLEASE NOTE: This is a complete full set of IM608S II + GBOX2 & APB112

New upgraded version

AUTEL NEW 2023 IM608S II Full Kit Diagnostic Key Programming Scanner Tool CarRadio.ie

AUTEL APB112 Smart Key Simulator

Autel APB112 smart key simulator is used to collect the data sent from the ignition coil, aiming to identify the ignition coil troubles and decode the data of the vehicle key chip. It can also simulate the vehicle key chip.

-AUTEL APB112 Function List:

1. Smart key simulator 2. Compatible with IM608, IM508 3. Compact but would need to be used with the XP400 4. Cannot be used with the XP200 5. 46, 4D data collection 6. 46 smart key password calculation 7. 46 chip simulation 8. For T0yota 4D (94/ D4, 98) smart key simulation 9.For T0yota H (88/ A8, A9, 39) smart key simulation 10. Collects data from the ignition coil 11. Identify ignition coil troubles 12. Decode vehicle key chip data 13. Simulate vehicle key chip (ex – 4D chip) 14. Must be used with an Autel diagnostic tool 15. For T0yota/ Lexus smart key all key lost.

Autel G-BOX2 Tool for Mercedes Benz All Key Lost Work with Autel MaxiIM IM608/IM508

1. Support Mercedes Benz All Key Lost, faster calculate password
2. Work together with both IM608 or IM508 with XP400
3. Used for Faster Mercedes ECU data and EIS password calculation
4. Mercedes DAS3 can EIS/EZS all keys lost
5. Reduces reading time of W204 ECU data & W207 EIS by over 85%
6. No need to remove and reinsert the key for W221 & W164 after 2009 Models

im608j2345Sin título-1autel_im608_6452bf03-a1f3-4d33-adb1-b177418c3a3a_1024x1024autel-im608key-programming-device-autel-maxim-im608







Autel MaxiIM IM608 is the most advanced and unique all-in-one key programming and diagnostic tool that combines advanced key programming, all systems diagnostics, and advanced services in one Android-based 10.1-inch touchscreen tablet. It is equipped with an XP400pro key programmer and MaxiFlash ECU programmer to provide complete coverage of IMMO and programming functions. Together with the ability to quickly diagnose all modules of the majority of the makes and models on the market, IM608 provides you with all special functions. It is the unprecedented key programming and diagnostic tool that you ever wanted


IM608 is a state-of-the-art 10-inch Android-based touchscreen tablet combining the most advanced key programming and immobilizer capabilities with OE-level diagnostics and service functions. Equipped with an XP400pro key programmer and MaxiFlash JVCI ECU programmer, IM608 is a comprehensive immobilizer and key programming tool and ideal for auto technicians and locksmiths.?It combines the most advanced key programming and immobilizer experience with advanced automotive diagnostics and service functions, a 10-inch Android-based, touch-screen tablet with the latest in art. Autel MaxiIM IM608s II, a comprehensive, ideal immobilizer and key programming tool for automobile technicians and locksmiths.




Autel MaxiIM IM608S II Highlights:

1. Free Update Online for 2 Year

2.Warranty for 12 Months.


4. OE-Level Diagnostic and Service Functions as MaxiSYS Pro

5.with XP400PRO and MaxiFlash JVCI for ECU Programming

6. Language: English, Spanish and French. (We can ship to Spain and France now)

7. Autel have released BMW CAS4/CAS4+ through OBD update!


Autel MaxiIM IM608S II Features:

The IM608S II is an OE-Level Diagnostic and Service Functions as MaxiSYS Pro with additional software and accessories for IMMO and key programming.

1. Extraordinarily powerful Cortex A7+A15 six-core processor

2. 10.1-inch LED capacitive touch screen with 1920×1200 resolution

3. Internal reliable 64GB On-board Memory for better performance

4. Built-in 8-megapixel rear camera with autofocus and flashlight

5. 802.11 a/b/g/n/ac Wi-Fi to access your favourite web resources

6. Open-source Android Operating System for fast boot-up and multitasking

7. Powerful combination of advanced key programming/all systems diagnostics/advanced maintenance services

8. Professional key programming equipped with XP400 key programmer and MaxiFlash ECU programmer for complete Immo coverage

9. Smart mode for guided and automated key learning

10. Expert mode for advanced key learning

11. Read PIN/CS (all key lost), generate key, key learning, remote learning

12. IMMO ECU reset/adaptation, refresh/coding

13. Read/write transponder data, ECU/MCU/EEPROM data (eg. 9S12 encryption chip), IC card, detect remote frequency

14. Powerful OE-level diagnostics for more than 80 US, Asian and European makes and models

15. Complete capabilities for codes, live data, active test, ECU information, adaptation, matching, coding etc.

16. All special functions, EPB, DPF, SAS, Oil reset, BMS, TPMS sensor ID relearn, etc.


Autel MaxiIM IM608S II Functions:

1. Read & Clear Fault Codes | Short description & code provided (can clear faults & warning lights)

2. Service Functions | Oil light / EPB / BMS / SAS / DAF etc

3. Access Live Data | Data from the ECU/Modulesnsors displayed in real-time (Oxygen sensor-rich/lean etc)

4. Actuation/Component Testing | Actuate (switch on/off) to diagnose functionality (relays, fans, locks etc)

5. Coding Functions | Allows you to change vehicle parts that need to be “coded” (Injectors, ABS, starters etc)

6. Flashing/ Reprogramming | Advanced updating/coding of ECUs online through a J2534 pass-through flashing device

7. Advanced Key Programming | IMMO functions, Transponder read/write/identify, MCU/EEPROM chip read/write





Connect the IM608S II tablet to the vehicle (via the Bluetooth VCI or Main Cable) and to the XP400 (via USB cable) to access IMMO-related functions, including Key Learning, Remote Control Learning, Remote Control Add, etc. The software provides two methods to access IMMO functions

1. Smart Mode – for Guided and Automated Key Learning – step by step through a series of functions.

2. Expert Mode – for Advanced Key Learning – select a specific function.

1). PIN / CS Reading (Full Lost)

2). Key Generation

3). Key Programming

4). Command Introduction

5). Backup / Repair IMMO Data

6). IMMO ECU Brain Reset / Adaptation

7). IMMO ECU Brain Reset / Coding

8). BENZ 3rd Generation IMMO Key Splicing, Full Lost, Key Programming

9). BMW FEM / BDC Key Programming and ECU Adaptation

10). BMW CAS4 / 3/2 Key Programming

11). VW / AUDI MQB Key Programming, 48 Transponder (96-bit) Key Splicing, Full Lost, A6 Full Lost and More …




Support PC

MCU / EEPROM Chips Read / Write

ECU Read / Write

MC9S12 Encryption Chip Read / Write

Key Read / Write

Mercedes Infrared Key Read / Write

Remote Frequency Detect

IC Card Read/Write




MaxiFlash JVCI ECU Programmer (Bluetooth/USB cable)

Connect the IM608 tablet to the vehicle via the OtoFlash (VCI) to perform extensive diagnostic and service functions.

1. All System Diagnostics

2. Auto Search / VIN Finding

3. Reading / Deleting Error Code

4. Viewing the Live Data Stream

5. View Records of Failure History

6. Store and Data Management Applications

7. MaxiFlash JVCI ECU Programmer (Bluetooth / USB Cable)



1. ECU Coding

2. All Special Functions, EPB, DPF, SAS, Oil Reset, BMS and TPMS Sensor ID Re-Programming etc.

3. 10.1-inch LCD Touch Screen-64GB Memory-Android Kit Floor-TURKISH LANGUAGE Support-15000mAh Li-polymer Battery-8.0 Megapixel Camera-Wi-Fi-Bluetooth



Autel MaxiIM IM608S II IMMO Vehicle List:



A1,A3,A4,A5,A6,RS4,B6,B7,RS5,RS6,A4 Allroad,A8,S8,Q3,RSQ3,Q5,Q7,R8,TT,




Citigo,Fabia India,Fabia,Kamiq,Karoq,Octavia,Rapid India,Rapid,Roomster,Superb,Yeti


Amarok,Arteon,Atlas,Beetle,Bora,BoraGli,Caddy,Crafter,EOS,Fox Africa,,Fox EU,Fox,GTI,Gol County,Gol(5U),Gol(5W),Golf PLUS,Golf/Rabbit(1K),Golf6 ESTATE,Jetta,Parati,Passat,Phaeton,Polo,Scirocco,Sharan,Suran,T-Roc,Tiguan,Touareg,Touran,Transporter5/Multivan,up,UP!/cross UP!


500,500L,500X prox,Albea,Boxer,Daily,Doblo,Doblo New,Ducato,Egea,Fiorino,Freemont,,Idea,Grande punto

,Jumper,Linea,Marea,Nemo,Ottimo,Palio,Palio RST,Panda,Perla,Promaster,Punto,Sinea,Stilo,Viaggio


Autel MaxiIM IM608 vs. IM508 Comparison Chart:




Autel MaxiIM IM608 VS MaxiIM IM508 VS Auro OtoSys IM600 VS IM100


 IM608S II Hardware

Processor: Qualcomm SDM660 Octa-core(4x 2.2 GHz(A73),4x 1.8 GHz(A53)
ROM: 128GB
BT: BT V5.0 + BR/EDR
Android Version: Android 10
Screen Size: 10.1inch
